Hydraulic Cylinder Welded Steel Pipe Astm A513 Cold Rolling With Dom Production

Ask Lasest Price
Brand Name :	TORICH
Model Number :	ASTM A513
Certification :	ISO 9001-2008 ISO 14001 EN 10204.3.1 CCS NK etc
Price :	600-1200 USD/TONS
Supply Ability :	60000 tons one year
Delivery Time :	4-8 weeks after order confirmed

Add to Cart

Product Details
Company Profile

Hydraulic Cylinder Welded Steel Pipe Astm A513 Cold Rolling With Dom Production

Hydraulic cylinder ASTM A513 Cold Rolling Welded Steel Tubes with DOM Production

ASTM A513
Electric-Resistance-Welded Carbon and Alloy Steel Mechanical Tubing
Applications: for Machinery, Mechanical Engineering

1. Standard:
ASTM A513 cold rolling welded precision steel tubes
2. Steel Grade:
SAE1010, SAE1020, other materials upon agreement with customers.

3. Production method:
Cold rolling on the weled steel tubes, to reach high accuracy on the OD and WT tolerance

4. Size range:
O.D.:6-350mm W.T.:1-15mm L:max12000mm

5. Packing:
In Hexagonal Bundles, with anti corrosion oil protection, with seaworthy packing

Deliver condition:

1. A.W.H.R. "as welded" from hot-rolled steel

2. A.W.C.R. "as welded" from cold-rolled steel

3. S.D.C.R. "sink-drawn", cold-rolled steel

5. M.D. mandrel drawn

6. S.S.I.D. special smooth inside diameter

Please specify the delivery condition when sending the enquiry!

Thermal condition:
1. No final thermal treatment
2. Stress relieved
3. Annealed
4. Normalized

Steel Grade and Chemical Compositions:
Steel Grade	C	Mn	P	S	Si	Cr	Mo
Steel Grade	max		max	max	max	min
1008	0.10	0.5	0.035	0.035
1010	0.08-0.13	0.30-0.60	0.035	0.035
1018	0.14-0.20	0.30-0.60	0.035	0.035
1020	0.17-0.23	0.30-0.60	0.035	0.035
1026	0.22-0.28	0.60-0.90	0.035	0.035
1035	0.31-0.38	0.60-0.90	0.035	0.035
4130	0.28-0.33	0.40-0.60	0.035	0.035	0.15-0.35	0.80-1.10	0.08-0.25
4140	0.38-0.43	0.75-1.00	0.035	0.035	0.15-0.35	0.80-1.10	0.15-0.25

Samples for quality checking avaiable:

Application:
Hydraulic Cylinder Welded Steel Pipe Astm A513 Cold Rolling With Dom Production

Q: Are you trading company or manufacturer ?

A: A professional steel pipes materials inventor, manufacturer and solution provider

Q: How long is your delivery time?

A: Generally it is 7-14 days if the goods are in stock. or it is 30-60 days if the goods are not in stock, it is according to quantity.

Q: Do you provide samples of stainless steel pipe ? is it free or extra ?

A: Yes, we could offer the sample for free charge but need pay the cost of freight.

Q: What is your terms of payment ?

A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
